Kothari Metalloys is a top tier Brass Pipes & Tubes Manufacturer in India. Our major goal is to meet the diversified demands of our clients across a wide range of industrial applications. We recognize the necessity of providing a diverse selection of goods that meet a variety of needs and criteria. Quality is at the center of our operations, and we are dedicated to ensuring that our products satisfy the highest standards.
As a prominent Brass Pipes & Tubes Stockist, we appreciate our clients confidence and endeavor to surpass their expectations at all times. We are dedicated to retaining our position as an industry leading Brass Pipes & Tubes Supplier, by providing a varied choice of high quality products and unrivaled customer service.
Kothari Metalloys is a leading Brass Pipes & Tubes Manufacturer in India. We offer a wide range of products to meet diverse industrial needs. Our extensive inventory includes ASTM B135 Brass Pipes, Brass Seamless Pipe, Brass Seamless Pipes & Tubes, and various other varieties available in different sizes, shapes, and grades. Recognizing that each customer has distinct needs, we go above and beyond to supply customized solutions.
| Specification | |
|---|---|
| Sizes | 1.5mm to 22.2mm (1.5mm to 150mm) |
| Thickness | 0.4 mm to 2.5 mm length 4 mtr, 5 mtr, 10 mtr, 15 mtr, 20 mtr, 50 mtr, 100 mtr |
| Length | Single Random, Double Random & Cut Length |
| End | Beveled End, Plain End, Treaded |
| Specification | ASTM B135, 443 / C443 / C44300 Brass Tube, ASTM B111, ASME SB111, 330 / C330 / C33000 Brass Tube, 272 / C272 / C27200 Yellow Brass Tube, C230 Brass Pipe, C23000, Cuzn37 Brass Pipe |
| Form | Round, Square, Rectangular |
| Alloy Name | CuZn40 | CuZn37 | CuZn36 | CuZn35 | CuZn33 | CuZn30 | CuZn15 | CuZn10 | CuZn05 |
|---|---|---|---|---|---|---|---|---|---|
| Trade Name | Muntz Metal | Yellow Brass | Yellow Brass | Yellow Brass | Yellow Brass | Cartridge Brass | Red Brass | Commercial Bronze | Gilding Metal |
| Standard Conformance | |||||||||
| IS | IS 410 | IS 410 | - | - | - | IS 410 | - | IS 2768 | IS 3167 |
| ASTM | C28000 | C272000 | C27000 | C27000 | C268000 | C26000 | C23000 | C22000 | C21000 |
| BS 2870 | CZ109 | CZ108 | CZ107 | CZ107 | CZ107 | CZ106 | CZ102 | CZ101 | CZ125 |
| DIN 17660 | 2.036 | 2.0321 | 2.0335 | - | 2.028 | 2.0265 | 2.024 | 2.023 | 2.022 |
| EN 1652 | CW509L | CW508L | CW507L | - | CW506L | CW505L | CW502L | CW501L | CW500L |
| JIS 3100 | C2801 | C2720 | - | C2680 | C2680 | C2600 | C2300 | C2200 | C2100 |
| Chemical Composition | |||||||||
| Copper (Cu%) | 60 | 63 | 64 | 65 | 67 | 70 | 85 | 90 | 94 - 98 |
| Zinc (Zn%) | 40 | 37 | 36 | 35 | 33 | 30 | 15 | 10 | Remaining |
| Other impurities (%) | <0.75 | <0.60 | <0.60 | <0.5 | <0.5 | <0.5 | <0.5 | <0.5 | <0.5 |
| Alloy Name | Trade Name | Temper | Hardness HV Min - Max |
Tensile Strength N/mm2 (Min) | Elongation% min |
|---|---|---|---|---|---|
| CuZn40 | Muntz Metal | Annealed (0) | 85 Max | 275 Min | 30 |
| Quarter Hard(HA) | 85-110 | 350 - 420 | 20 | ||
| Half Hard (HB) | 100-125 | 420 - 490 | 12 | ||
| Hard (H) | 125-155 | 490 Min | 5 | ||
| Extra Hard (HE) | 160 - 180 | 565 Min | - | ||
| Spring Hard (HS) | - | - | - | ||
| Cuzn37 | Yellow Brass | Annealed (0) | 80 Max | 275 Min | 40 |
| Quarter Hard(HA) | 75-110 | 335 - 380 | 30 | ||
| Half Hard (HB) | 110-135 | 380-450 | 15 | ||
| Hard (H) | 135-165 | 450-515 | 5 | ||
| Extra Hard (HE) | 165-185 | 515-660 | - | ||
| Spring Hard (HS) | 185 Min | 660 Min | - | ||
| Cuzn36 | Yellow Brass | Annealed (0) | 80 Max | 275 Min | 40 |
| Quarter Hard(HA) | 75-110 | 335-380 | 30 | ||
| Half Hard (HB) | 110-135 | 380-450 | 15 | ||
| Hard (H) | 135-165 | 450-515 | 5 | ||
| Extra Hard (HE) | 165-185 | 515-660 | - | ||
| Spring Hard (HS) | 185 Min | 660 Min | - | ||
| Cuzn35 | Yellow Brass | Annealed (0) | 80 Max | 275 Min | 40 |
| Quarter Hard(HA) | 75-110 | 335-380 | 30 | ||
| Half Hard (HB) | 110-135 | 380-450 | 15 | ||
| Hard (H) | 135-165 | 450-515 | 5 | ||
| Extra Hard (HE) | 165-185 | 515-660 | - | ||
| Spring Hard (HS) | 185 Min | 660 Min | - | ||
| Cuzn33 | Yellow Brass | Annealed (0) | 80 Max | 275 Min | 40 |
| Quarter Hard(HA) | 75-110 | 335-380 | 30 | ||
| Half Hard (HB) | 110-125 | 380 | 15 | ||
| Hard (H) | 135-165 | 450-515 | 5 | ||
| Extra Hard (HE) | 165-185 | 515-660 | - | ||
| Spring Hard (HS) | 185 Min | 660 Min | - | ||
| Cuzn30 | Cartridge Brass | Annealed (0) | 80 Max | 275 Min | 50 |
| Ouarter Hard(HA) | 75-100 | 320-345 | 35 | ||
| Half Hard (HB) | 100-125 | 345-405 | 20 | ||
| Hard (H) | 125 Min | 405 Min | 5 | ||
| Extra Hard (HE) | 150 Min | 480 Min | - | ||
| Spring Hard (HS) | 185 Min | 655 Min | - | ||
| Cuzn15 | Red Brass | Annealed (0) | 55-75 | 245 Min | 35 |
| Quarter Hard(HA) | 75-95 | 275-325 | 15 | ||
| Half Hard (HB) | 95-110 | 325-375 | 7 | ||
| Hard (H) | 110 - 140 | 350 Min | 3 | ||
| Extra Hard (HE) | 140 - 160 | 480 Min | - | ||
| Spring Hard (HS) | 155 - 180 | 540 Min | - | ||
| Cuzn10 | Commercial Bronze | Annealed (0) | 55-75 | 245 Min | 35 |
| Quarter Hard(HA) | 75-95 | 275 - 325 | 15 | ||
| Half Hard (HB) | 95-110 | 325-375 | 7 | ||
| Hard (H) | 110 - 140 | 350 Min | 3 | ||
| Extra Hard (HE) | 130 - 145 | 440 MIn | - | ||
| Spring Hard (HS) | 140 - 160 | 475 Min | - | ||
| Cuzn05 | Gilding Brass | Annealed (0) | 55-75 | 230 - 280 | 35 |
| Quarter Hard(HA) | 70 - 90 | 255-325 | 12 | ||
| Half Hard (HB) | 80 - 100 | 290 - 355 | 7 | ||
| Hard (H) | 100 - 115 | 345 Min | 3 | ||
| Extra Hard (HE) | 115-125 | 385 Min | - | ||
| Spring Hard (HS) | 120 - 135 | 415 Min | - |
Kothari Metalloys is a leading Brass Pipes & Tubes Manufacturer, Supplier & Stockist in India.
As a market leading Brass Pipes & Tubes Supplier, we supply our products to all major nations across the globe, including Saudi Arabia, the United States, South Africa, and Mexico. We are a major Brass Pipes & Tubes Stockist with a significant position in the worldwide industry. We are continually growing our reach by connecting with new clientele in various areas of the world.
