Kothari Metalloys is a leading Brass Busbar Stockist in India. We comprehend that different industries have different needs, which is why we provide personalized solutions. Our knowledgeable staff works hard with customers to understand their requirements and provide custom-made bus bars that meet their exact specifications. Because of our commitment to customer satisfaction, we have established ourselves as a dependable Brass Busbar Supplier offering customized bars all over the world.
We are always aiming for excellence in both product quality and customer service at our company. As a leading Brass Busbar Supplier, we engage in innovative supplying methods and strict quality control systems to ensure that our bus bars exceed industry standards. We are also a well known Brass Busbar Stockist, offering these products in different sizes, grades, specifications & thicknesses as per the client’s requirements.
Our Brass Bars are produced using a premium grade brass wire to provide great electrical conductivity and thermal efficiency. As a leading Brass Busbar Stockist, we employ innovative manufacturing techniques and strong quality control systems to deliver goods that exceed the highest industry standards. We are also a known Brass Busbar Supplier in India.
| Brass Busbar | Specification |
|---|---|
| Material | Brass |
| Type | Straight Bar |
| Width | 10mm to 300mm |
| Thickness | 1mm (min) to 50mm (max) |
| Length | Straight Length: 1mtr to 6mtr |
| Grade | C36000, C46400, C48500, C37700, C28000 |
| Temper | Soft (Annealed) | Half Hard | Quarter Hard |
| Alloy Name | CuZn40 | CuZn37 | CuZn36 | CuZn35 | CuZn33 | CuZn30 | CuZn15 | CuZn10 | CuZn05 |
|---|---|---|---|---|---|---|---|---|---|
| Trade Name | Muntz Metal | Yellow Brass | Yellow Brass | Yellow Brass | Yellow Brass | Cartridge Brass | Red Brass | Commercial Bronze | Gilding Metal |
| Standard Conformance | |||||||||
| IS | IS 410 | IS 410 | - | - | - | IS 410 | - | IS 2768 | IS 3167 |
| ASTM | C28000 | C272000 | C27000 | C27000 | C268000 | C26000 | C23000 | C22000 | C21000 |
| BS 2870 | CZ109 | CZ108 | CZ107 | CZ107 | CZ107 | CZ106 | CZ102 | CZ101 | CZ125 |
| DIN 17660 | 2.036 | 2.0321 | 2.0335 | - | 2.028 | 2.0265 | 2.024 | 2.023 | 2.022 |
| EN 1652 | CW509L | CW508L | CW507L | - | CW506L | CW505L | CW502L | CW501L | CW500L |
| JIS 3100 | C2801 | C2720 | - | C2680 | C2680 | C2600 | C2300 | C2200 | C2100 |
| Chemical Composition | |||||||||
| Copper (Cu%) | 60 | 63 | 64 | 65 | 67 | 70 | 85 | 90 | 94 - 98 |
| Zinc (Zn%) | 40 | 37 | 36 | 35 | 33 | 30 | 15 | 10 | Remaining |
| Other impurities (%) | <0.75 | <0.60 | <0.60 | <0.5 | <0.5 | <0.5 | <0.5 | <0.5 | <0.5 |
| Alloy Name | Trade Name | Temper | Hardness HV Min - Max |
Tensile Strength N/mm2 (Min) | Elongation% min |
|---|---|---|---|---|---|
| CuZn40 | Muntz Metal | Annealed (0) | 85 Max | 275 Min | 30 |
| Quarter Hard(HA) | 85-110 | 350 - 420 | 20 | ||
| Half Hard (HB) | 100-125 | 420 - 490 | 12 | ||
| Hard (H) | 125-155 | 490 Min | 5 | ||
| Extra Hard (HE) | 160 - 180 | 565 Min | - | ||
| Spring Hard (HS) | - | - | - | ||
| Cuzn37 | Yellow Brass | Annealed (0) | 80 Max | 275 Min | 40 |
| Quarter Hard(HA) | 75-110 | 335 - 380 | 30 | ||
| Half Hard (HB) | 110-135 | 380-450 | 15 | ||
| Hard (H) | 135-165 | 450-515 | 5 | ||
| Extra Hard (HE) | 165-185 | 515-660 | - | ||
| Spring Hard (HS) | 185 Min | 660 Min | - | ||
| Cuzn36 | Yellow Brass | Annealed (0) | 80 Max | 275 Min | 40 |
| Quarter Hard(HA) | 75-110 | 335-380 | 30 | ||
| Half Hard (HB) | 110-135 | 380-450 | 15 | ||
| Hard (H) | 135-165 | 450-515 | 5 | ||
| Extra Hard (HE) | 165-185 | 515-660 | - | ||
| Spring Hard (HS) | 185 Min | 660 Min | - | ||
| Cuzn35 | Yellow Brass | Annealed (0) | 80 Max | 275 Min | 40 |
| Quarter Hard(HA) | 75-110 | 335-380 | 30 | ||
| Half Hard (HB) | 110-135 | 380-450 | 15 | ||
| Hard (H) | 135-165 | 450-515 | 5 | ||
| Extra Hard (HE) | 165-185 | 515-660 | - | ||
| Spring Hard (HS) | 185 Min | 660 Min | - | ||
| Cuzn33 | Yellow Brass | Annealed (0) | 80 Max | 275 Min | 40 |
| Quarter Hard(HA) | 75-110 | 335-380 | 30 | ||
| Half Hard (HB) | 110-125 | 380 | 15 | ||
| Hard (H) | 135-165 | 450-515 | 5 | ||
| Extra Hard (HE) | 165-185 | 515-660 | - | ||
| Spring Hard (HS) | 185 Min | 660 Min | - | ||
| Cuzn30 | Cartridge Brass | Annealed (0) | 80 Max | 275 Min | 50 |
| Ouarter Hard(HA) | 75-100 | 320-345 | 35 | ||
| Half Hard (HB) | 100-125 | 345-405 | 20 | ||
| Hard (H) | 125 Min | 405 Min | 5 | ||
| Extra Hard (HE) | 150 Min | 480 Min | - | ||
| Spring Hard (HS) | 185 Min | 655 Min | - | ||
| Cuzn15 | Red Brass | Annealed (0) | 55-75 | 245 Min | 35 |
| Quarter Hard(HA) | 75-95 | 275-325 | 15 | ||
| Half Hard (HB) | 95-110 | 325-375 | 7 | ||
| Hard (H) | 110 - 140 | 350 Min | 3 | ||
| Extra Hard (HE) | 140 - 160 | 480 Min | - | ||
| Spring Hard (HS) | 155 - 180 | 540 Min | - | ||
| Cuzn10 | Commercial Bronze | Annealed (0) | 55-75 | 245 Min | 35 |
| Quarter Hard(HA) | 75-95 | 275 - 325 | 15 | ||
| Half Hard (HB) | 95-110 | 325-375 | 7 | ||
| Hard (H) | 110 - 140 | 350 Min | 3 | ||
| Extra Hard (HE) | 130 - 145 | 440 MIn | - | ||
| Spring Hard (HS) | 140 - 160 | 475 Min | - | ||
| Cuzn05 | Gilding Brass | Annealed (0) | 55-75 | 230 - 280 | 35 |
| Quarter Hard(HA) | 70 - 90 | 255-325 | 12 | ||
| Half Hard (HB) | 80 - 100 | 290 - 355 | 7 | ||
| Hard (H) | 100 - 115 | 345 Min | 3 | ||
| Extra Hard (HE) | 115-125 | 385 Min | - | ||
| Spring Hard (HS) | 120 - 135 | 415 Min | - |
As a leading Brass Round Bar Stockist, we offer an extensive range of brass alloys to cater to a wide array of industrial applications. Whether you require enhanced machinability, excellent corrosion resistance, or superior electrical conductivity, our comprehensive selection of brass alloys is designed to meet your specific requirements.
| Alloy | Related Standards | Size Range | Related Standard Applications |
|---|---|---|---|
| 95/5 Br.C21000 90/10 Br. C22000 80/20 Br. C23000 70/30 Br. C26000 63/37 Rr. C27400 Naval Br. C46400 |
BS 2874 ASTM B 21, B 135, B 43 DIN 17665 JIS H3250 |
16 mm to 250 mm | Condenser Components Marine hardware Welding Rods Rivet Valves Piston Rods. |
Kothari Metalloys is a leading Brass Busbar Supplier & Stockist in India.
As a leading Brass Busbar Stockist, we have earned a significant position in the global market. Our continual growth is the result of our unrelenting efforts to connect with new clients in various regions of the world. We are also well-known as a dependable Brass Busbar Supplier.
| Countries We Export | ||
|---|---|---|
| Saudi Arabia | Qatar | Canada |
| Sri Lanka | Iran | Nigeria |
| Bangladesh | Oman | UAE |
| Turkey | Kuwait | Venezuela |
| Africa | Singapore | Netherlands |
| United Kingdom | Mexico | Malaysia |
| United States | Australia | Japan |
